Frozen mouse muscle tissue section stained for BAG3 expression using ab47124 at 1/2000. The tissue section was fixed in 3.8% paraformaldehyde prior to staining. BAG3 localizes with Z-disk proteins."

Immunohistochemistry of formalin fixed paraffin embedded human pancreas tissue sections using ab47124 at 1/2000. A, normal pancreas. B and C, pancreatic cancer. Hematoxylin-eosin counterstain.

ICC/IF image of ab47124 stained HeLa cells. The cells were 4% formaldehyde fixed (10 min) and then incubated in 1%BSA / 10% normal goat serum / 0.3M glycine in 0.1% PBS-Tween for 1h to permeabilise the cells and block non-specific protein-protein interactions. The cells were then incubated with the antibody (ab47124, 5µg/ml) overnight at +4°C. The secondary antibody (green) was ab96899, DyLight® 488 goat anti-rabbit IgG (H+L) used at a 1/250 dilution for 1h. Alexa Fluor® 594 WGA was used to label plasma membranes (red) at a 1/200 dilution for 1h. DAPI was used to stain the cell nuclei (blue) at a concentration of 1.43µM.
